Technical Specifications of DF-10 AI Face Recognition Terminal
| Parameter | Specification |
|---|---|
| Model | DFACE DF-10 |
| CPU | 1.2GHz Dual-Core ARM Cortex-A7 |
| RAM | 256MB DDR3L |
| Storage (ROM) | 4GB eMMC |
| Camera Sensor | Real Sensor 1/2.9″ |
| Camera Resolution | 2MP HD Color Camera |
| Wide Dynamic Range | Supported |
| Field of View | 60° |
| Infrared Camera | Supported |
| Display | 5-inch Touch Screen |
| Screen Resolution | 800 × 480 |
| Verification Methods | Face, Fingerprint, RFID Card (Optional), Password |
| Recognition Time | ≤ 1 Second |
| Face Capacity | 3,000 Users |
| Fingerprint Capacity | 3,000 Users |
| RFID Card Capacity | 5,000 Cards |
| Attendance Logs | 100,000 Records |
| Communication | TCP/IP, WiFi (2.4GHz), USB 2.0 |
| Relay Output | Supported |
| Wiegand | 26/34 |
| Door Sensor | Supported |
| Exit Button | Supported |
| Alarm Output | Supported |
| Recognition Distance | 0.5–2.5 meters |
Applications
- Corporate Offices
- Commercial Buildings
- Banks & Financial Institutions
- Schools & Universities
- Hospitals & Clinics
- Factories & Warehouses
- Government Buildings
- Hotels
- Retail Stores
- Industrial Facilities
Key Features
- AI Face Recognition Technology
- Fingerprint Authentication
- RFID Card Support
- Password Verification
- Infrared Live Body Detection
- 5-inch HD Touch Display
- Recognition Time ≤ 1 Second
- Recognition Distance: 0.5–2.5 meters
- Stores up to 3,000 Faces
- Stores up to 3,000 Fingerprints
- Supports 5,000 RFID Cards
- Stores 100,000 Attendance Logs
- Automatic Photo Capture
- TCP/IP Network Communication
- Built-in WiFi Connectivity
- USB 2.0 Data Transfer
- Multi-language Interface
- OEM Custom Screen Saver Support
- Wiegand 26/34 Interface
- Door Sensor & Exit Button Support
- Alarm Output
- Fast and Accurate AI Recognition
Product Description
The DF-10 AI Face Recognition Terminal is a next-generation biometric access control and time attendance solution designed to deliver intelligent security, accurate employee attendance, and seamless access management for modern organizations. Combining advanced artificial intelligence with multiple authentication methods, the DF-10 AI Face Recognition Terminal provides businesses with a reliable, secure, and efficient way to control entry while eliminating traditional attendance errors.
Powered by advanced AI facial recognition algorithms, the DF-10 AI Face Recognition Terminal identifies authorized users in less than one second with exceptional accuracy. The intelligent recognition engine quickly verifies employees, visitors, and authorized personnel, significantly reducing waiting times during peak office hours. Whether installed in corporate offices, factories, schools, hospitals, warehouses, retail stores, or government facilities, the DF-10 AI Face Recognition Terminal delivers fast and dependable biometric authentication every day.
The DF-10 AI Face Recognition Terminal supports multiple verification methods, giving organizations the flexibility to choose the authentication process that best suits their security requirements. Users can gain access through AI face recognition, fingerprint authentication, RFID card verification, password entry, or a combination of these methods for enhanced security. This multi-authentication capability ensures maximum convenience while maintaining strict access control across all types of facilities.
Built with a vibrant 5-inch HD color touch screen, the DF-10 AI Face Recognition Terminal offers an intuitive and user-friendly interface. The responsive display allows administrators and employees to navigate menus, enroll users, and manage attendance records with ease. The modern interface improves the overall user experience while simplifying daily operation and system administration.
One of the most advanced features of the DF-10 AI Face Recognition Terminal is its infrared live body detection technology, which effectively prevents spoofing attempts using printed photographs, digital images, or video recordings. This intelligent anti-spoofing technology ensures that only genuine users are granted access, providing an additional layer of security for businesses that require reliable identity verification.
Designed for growing organizations, the DF-10 AI Face Recognition Terminal supports an impressive user capacity of 3,000 facial templates, 3,000 fingerprint templates, 5,000 RFID cards, and up to 100,000 attendance records. This high-capacity storage makes the DF-10 AI Face Recognition Terminal suitable for small businesses, medium-sized enterprises, educational institutions, healthcare facilities, manufacturing plants, commercial buildings, and large corporate organizations.
Available at A to Z Security Equipment Trading LLC in Dubai, UAE and Kigali Smart solution in Rwanda, Africa.
Product Brochure: DFACE DF-10 AI Face Recognition & Fingerprint Access Control Terminal With Time Attandance
